P897V Test and Measurement Grade Vacuum Pressure Transducer
- 0.1% FS Accuracy
- FS Ranges from 2.22 In H2O
- Low Temperature Error
- +/-5 Vdc and 4-20 mA Output Signals
- Ordering Options for Vacuum Signal Direction
- 0 to +5 Vdc as Vacuum Increases
- 0 to -5 Vdc as Vacuum Increases
- 4-20 mA as Vacuum Increases
Category: Pressure Transducers and Transmitters
Tags: canbus pressure, canbus pressure measurement, canbus pressure transducer, differential pressure, high pressure, low pressure, pressure sensor, pressure transducers, pressure transmitters, rugged, rugged pressure sensor, test and instrumentation pressure sensor
The P897V is ideal for:
- Low Vacuum Pressure Measurement
- Automotive Test Cells
- Any High Accuracy Application
The P897V is designed for a wide variety of pressure measurements where high resistance to vibration and superior stability through temperature change is required. The zero and full-scale output calibrations are set by the potentiometer adjustments accessible from the top cover. The P897V is digitally compensated and corrected to provide high accuracy pressure measurement in a robust cylindrical form factor. Small vacuum pressures are accurately measured with full scale vacuum ranges as low as 2.22 InH2O.
The P897V is DC powered and is available in the most popular analog out versions including 0 to +/-5Vdc and 4-20mA. A CANBus, USB and Serial Version is also available.
